• TMS Series

    TMS Series

    ·Constant Voltage non dimmable on/off driver.
    ·Full range input voltage 120-277VAC.
    ·High PF, high efficiency, low THD.
    ·SELV and Class P design.
    ·UL certification.
    ·Suitable for dry, damp and wet location (IP67).
    ·Nominal lifetime up to 100,000 h.
    ·5-year warranty.
  • /upload/images/20251017/59923113233e3054a595a14626bc5ed0.png

Parameters

Part No.Input VoltageOutput PowerOutput VoltageOutput CurrentPower FactorCertificateDimension(mm)

TMS-24V150W-NWA

120-277VAC150W MAX.24VDC6.25A>0.95

UL/cUL/FCC/

Class P/TYPE HL/RoHS

L185*W68*H40mm

[L7.3*W2.7*H1.6in.]

TMS-24V200W-NWA

120-277VAC200W MAX.24VDC8.33A >0.95

UL/cUL/FCC/

Class P/TYPE HL/RoHS

L216*W68*H40mm

[L8.5*W2.7*H1.6in.]

TMS-24V300W-NWA120-277VAC

300W MAX.

24VDC12.5A>0.95

UL/cUL/Class P/

TYPE HL/RoHS

L220*W90*H46mm

[L8.7*W3.5*H1.8in.]
